Description
ALLEN BRADLEY 20-750-DNET
Communications Module, Powerflex 750,DeviceNet, 125-500Kbps
Revisions: Ser A
Description: The Allen-Bradley 20-750-DNET is a DeviceNet Option Module. This module comes with one (1) DeviceNet communication interface and one (1) Drive Peripheral Interface (DPI). This module has a current consumption of 50 milliamperes at 14 Volts DC supplied by the host drive and 60 milliamperes at 24 Volts DC supplied by the network. It has captive screws for secured mounting and grounding connection and rotary switches for setting module address.
Technical Specifications for 20-750-DNET
| Part Number | 20-750-DNET |
| Brand | Allen-Bradley |
| Weight | 62 g (2.1 oz) |
| Module Type | DeviceNet communication module |
| Product Family | PowerFlex 7 Series |
| Compatible Drives | PowerFlex 753 / PowerFlex 755 |
| DeviceNet communication rate | 125 Kbps, 250 Kbps, 500 Kbps or Autobaud |
| Current consumption, Drive | 50 mA at 14V DC |
| Current consumption, network | 60 mA at 24V DC |
| Dimensions | H: 68 mm (2.7 inches) L:150 mm (5.9 inches) W:26 mm (1.0 inches) |
| Operating Temperature | -10…50 °C (14…122 °F) |
| Non-operating Temperature | -40…85 °C (-40…185 °F) |
| Relative Humidity | 5…95% noncondensing |
| Product Type | DeviceNet Option Module |
| Manufacturer | Rockwell Automation |
| Used with | Powerflex 755 |
| Data Rate | 500 Kbps |
| Electrical Consumption | 50 mA @ 14V DC |
| Drive Protocol | DPI |
| Network Protocol | 62 g |
| UPC | 820919992490 |
