AVENTICS 5772555302
AVENTICS – 5772555302 – 3/2-directional valve, Series CD04 (CD04-3/2NC-SR-NONE-I-G018-G018)
3/2-directional valve, Series CD04
– 3/2
– Qn = 900 l/min
– Pilot valve width : 26 mm
– NC, NO
– Pipe connection
– Compressed air connection output : G 1/8
– Electrical connection : Plug, EN 175301-803, form B, 3-pin
– Manual override : with detent without
– single solenoid
– With spring return
– Pilot : Internal External
Part Number: 5772555302
| Weight | 0.268 kg |
|---|---|
| Electrical interface | EN 175301-803, Form B |
| Manual override | with detent |
| Connection output | G 1/8 |
| Connection exhaust | G 1/8 |
| Flow Qn | 900l/min |
| Ambient Temperature Max | 50DegC |
| Ambient Temperature Min | -15DegC |
| Connection input | G 1/8 |
| Working Pressure Max | 10 Bar |
| Working Pressure Min | 3 Bar |
